Stainless Steel Flanged Globe Valve

Flanged Globe Valve Compliant with API 600, ASME B16.34, and ANSI B16.5 standards. Core Definition A specialized flow control device engineered for regulating liquids and gases in industrial and commercial piping systems. It features a disk-shaped valve plug (globe) and flanged ends, providing a secure bolted connection to pipelines for reliable fluid management. Structure & Operating Principle – Key Components: Disk-shaped valve plug, flanged valve body, and manual handle (or actuator for automated models). – Operating Mechanism: Rotating the handle drives the valve stem, which moves the disk plug vertically within the valve body-lowering the plug blocks flow, while raising it allows fluid passage, enabling precise throttling and on/off control. – Connection Method: Flanged ends bolted to matching pipe flanges, ensuring leak-tight integration and straightforward maintenance. Performance Advantages – Precise flow control: The disk plug’s design enables accurate throttling and shutoff, ideal for applications requiring regulated flow rates. – Robust sealing: Flanged connection and precision-machined valve seat ensure tight, leak-proof performance in long-term operation. – Durable construction: Engineered with high-grade materials to withstand industrial operating conditions, delivering reliable service life. – Versatile compatibility: Suitable for both liquid and gas media, adapting to diverse industrial and commercial piping requirements. Key Specifications – Pressure Rating: PN10 – PN420 / Class 150 – 2500. – Operating Temperature: -29℃ – 425℃ (carbon steel body) / -196℃ – 550℃ (stainless steel body). – Body Materials: Carbon Steel (A216 WCB), Stainless Steel (A351 CF8/CF8M), Alloy Steel (A217 WC6/WC9). – End Connection: Flanged (ANSI B16.5, DIN EN 1092-1) – compatible with standard industrial pipe flanges. Application Fields – Industrial Piping Systems: Oil & gas transmission, chemical processing, petrochemicals, power generation, water treatment, metallurgy, and steam systems. – Commercial & Infrastructure: Municipal water supply, HVAC systems, industrial boilers, compressed air pipelines, and commercial building fluid control networks.
